Orbea VIBE MID H10 EQ

Orbea VIBE MID H10 EQ
  • Color: Light Green Gloss
  • Color: Night Black Gloss
  • Color: Blue Gloss
  • Color: Metallic Dark Red Gloss
  • Color: Urban Green Gloss
$3,279.00
Please select options
Order now and pick up in-store for free

Details

URBAN LIGHTNESS
In the spirit of urban function and easy use, we have developed a new transportation concept designed for your life. A machine that is also a sophisticated accessory that echoes your sense of style without overshadowing it—a sleek, fun, reliable tool that can be easily maneuvered into apartments or workplaces.

Vibe is a bike that is lightweight and enjoyable to ride—with a motor, battery, and integrated electronics system designed for the fast-paced, grab-and-go lifestyle of the city.

INTEGRATED LIGHTS
- It's like magic—Fully integrated lighting is just one more feature to enhance your ride. Vibe is safer and more functional with head and tail lamps that announce your presence day and night. With full-time running lights and an optional high-beam light, Vibe is ready for the road.

IWOC TRIO
- Vibe's control center is an attractive and discreet handlebar-mounted switch, putting function at your fingertips without removing your hands from the bar.
- On, off, and light control
- Battery & assist level
- Information by RBG LED
- Smart & compact

INTERNAL BATTERY
- The battery is one of the most noticeable components of an eBike system, so every step has been taken to find the lightest, smallest, and most discreet unit. Vibe's Enough Energy concept provides you enough battery power, not more. It eliminates the need for a bulky, high-output battery that needs to be removed from the bike.

PAS SENSOR
- Vibe's smooth and balanced assist requires an advanced sensor. Blending perfectly with our effort to create a sleek and discrete system, the cassette lock ring is replaced with a PAS sensor that monitors your pedaling input and adjusts power accordingly.
- 40 pulses per second
- Magnetized lock ring sensor
- Proprietary algorithm & electronics

ICR PLUS
- Internal Cable Routing is carefully guided along the best path under the stem and through the head tube with no rub or rattle and is optimized for both traditional and electronic shifting systems. Proprietary headset spacers smooth airflow and offer easy adjustment.

Specs

Frame Orbea Vibe Mid Bar Hydro 6061 Hydroform Aluminum 2021, ICR cable routing, Forged BB, 135x9 QR, Flat Mount disc, 700x40 maximum tire, 1-1/2" semi-integrated headset, 41x86.5 Pressfit BB, carrier, and fender compatible
Fork Orbea Vibe carbon fork, full carbon, 1-1/2", 700x40 maximum tire, flat mount disc mount, Thru-Axle12x100mm, Long fender compatible
Wheels Ready GR
Tires Kenda K1052 700x45C Reflective type TLR
Crankset OC 42t, w/Chainguard
Shifters Shimano Deore M6100
Rear Derailleur Shimano XT M8100 SGS Shadow Plus
Cassette/Freewheel Sun Race 11-51t 12-Speed
Chain KMC X12
Brakes Magura MT5 E-STOP Hydraulic Disc Easy Route Connection
Handlebars Alloy 31.8mm 12mm RISE 700mm
Tape/Grips Brooks Comfort Cambium 130mm
Stem OC1 31.8mm interface -6º
Headset Acros Alloy 1-1/2" Internal Cable Routing
Seatpost Alloy 27.2 Offset 20
Saddle Brooks Cambium C19 275x184
Pedals VP-537 Black
Accessories & Extras Rear Carrier: Orbea Vibe rear luggage carrier (Max:15Kg)
Carrier Accessories: OC Carrier side bag, backpack convertible with inner computer bag, 15L, waterproof, reflective
Mudguard: CURANA Apollo 55mm
Front Light: Lezyne Ebike POWER STVZO PRO E115 inverted position with remote 310 lumens
Rear Light: Lezyne FENDER STVZO
Quick Stand: Ursus Mooi R90 rear alloy adjustable
Bell: Knog Oi Classic
Motor Ebikemotion X35 Plus 20mph
Battery Ebikemotion 36V/6.9A 248Wh ANT+
Controller/Display Ebikemotion iWoc TRIO
Charger Ebikemotion X35

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Light Green Gloss / Small 08434446789779 L64446YJ
Light Green Gloss / Medium 08434446789878 L64449YJ
Light Green Gloss / Large 08434446789946 L64453YJ
Night Black Gloss / Small 08434446789694 L64446YF
Night Black Gloss / Medium 08434446789793 L64449YF
Night Black Gloss / Large 08434446789892 L64453YF
Blue Gloss / Small 08434446789717 L64446YG
Blue Gloss / Medium 08434446789816 L64449YG
Blue Gloss / Large 08434446789915 L64453YG
Metallic Dark Red Gloss / Small 08434446789731 L64446YH
Metallic Dark Red Gloss / Large 08434446789922 L64453YH 210000031432
Urban Green Gloss / Small 08434446789755 L64446YI
Urban Green Gloss / Medium 08434446789854 L64449YI
Urban Green Gloss / Large 08434446789939 L64453YI
